PRO-WSME-500

Home > Product > TIG WELDERS (GTAW) > PRO-WSME-500

PRO-WSME-500

description1

Zipper closure 1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout

Information

Item	PRO-WSME-315	PRO-WSME-400	PRO-WSME-500
Rated Input Voltage(V)	3ph,220V/380V/415V/440V+15%	3ph,220V/380V/415V/440V+15%	3ph,220V/380V/415V/440V+15%
Input Frequency(Hz)	50/60	50/60	50/60
Rated Input Power(KVA)	14.5	20	26
Output Current(A)	10-315	10-400	10-500
Rated Output Voltage(V)	10.4-22.6	10.6-26.3	10.8-30
Open Circuit Voltage(V)	64	67	69
Striking Current Adjusting Range(A)	20-160	20-160	20-160
ARC Current Adjusting Range(A)	10-315	15-400	20-500
Base Value Current Adjusting Range(A)	10-315	10-400	10-500
Peak Current Adjusting Range(A)	10-315	15-400	20-500
Pulse Duty Ration(%)	1-99	1-99	1-99
Impulse Frequency(Hz)	0.1-20	0.1-20	0.1-20
Clearance Rate Range(%)	-40~+40	-40~+40	-40~+40
AC Bias Range(%)	-50~+30	-50~+30	-50~+30
AC Frequency Range(Hz)	20-200	20-200	20-200
Ahead Of Time(S)	0.1-5	0.1-5	0.1-5
Lag Time(S)	1-10	1-10	1-10
Ramp Time(S)	0.1-10	0.1-10	0.1-10
Slow Down Time(S)	0.1-10	0.1-10	0.1-10
Rated Duty Cycle(%)	100%	100%	100%
Weight(Kg)	170	170	190
